The 5 Gigabit compatible TP-DC-1256GD-BT are very high power DC to DC converters / Bluetooth PoE inserters designed for the latest 802.3bt PoE standard. The unique PoE inserter supplies 56VDC Class 8 802.3bt PoE power on all 8 Ethernet wires (4 Pair). They support data throughput rates to 5Gigabit. They are backward compatible with 802.3at devices.
The wide input voltage range (10VDC to 60VDC) makes these units universal in battery-powered applications. This flexibility ensures they can be used in various scenarios, including remote and mobile installations. The units’ input/output is isolated, so they work seamlessly in either a negative ground or positive ground system, adding to their versatility.
The TP-DC-1256GD-BT Bluetooth POE inserter features a locking DC wire terminal connector with two DC inputs for connecting 2 power sources, such as a primary and backup power source. This redundancy ensures continuous operation even if one power source fails. The units also incorporate various protections for low voltage, surge, short circuit, and overload, providing robust and reliable performance.
Constructed with a durable metal housing, the TP-DC-1256GD-BT is designed to withstand harsh environments. It comes complete with a DIN Rail mounting kit for easy installation on a standard DIN rail, making it suitable for industrial applications. Its compact dimensions and lightweight design facilitate integration into existing systems without significant modifications.
Ideal for use in high-demand network environments, these converters/ Bluetooth POE inserter ensure reliable power delivery and data transmission, supporting modern, high-bandwidth applications. Whether deployed in telecommunications, industrial automation, or remote monitoring systems, the TP-DC-1256GD-BT offers exceptional performance and reliability.
